Programmable LED Driver
NFC-Programmable Constant Current LED Drivers for Flexible LED Lighting Applications
Flexible NFC Programming for Adjustable LED Lighting Performance
ANTRON Programmable LED Drivers provide flexible output-current programming for a wide range of LED lighting applications. With NFC programming technology, the output current can be configured with 50 mA precision, allowing one LED driver platform to support multiple lighting fixture requirements.
Available from 25W to 149W, these programmable constant-current LED drivers help lighting manufacturers simplify product selection, reduce inventory requirements, and optimize LED fixture performance.
Output parameters can be programmed using an NFC programming tool or compatible smart devices. The drivers also support programmable minimum dimming levels, including dim-to-1%, dim-to-10%, and dim-to-off, providing greater flexibility for commercial, industrial, and indoor LED lighting applications.
Why Choose a Programmable LED Driver?
A programmable LED driver allows the output current to be configured according to the requirements of the LED fixture. Instead of stocking multiple LED driver models with different fixed output currents, manufacturers can use one programmable platform for multiple LED lighting designs.
One Driver Platform for Multiple LED Fixtures
Adjust the output current to match different LED modules and fixture designs, helping simplify product selection and reduce the number of driver models required.
Precise Output Current Programming
NFC programming enables output-current adjustment with 50 mA precision, providing accurate configuration for different LED lighting applications.
Flexible Minimum Dimming Levels
The minimum dimming level can be programmed to dim-to-1%, dim-to-10%, or dim-to-off, depending on the lighting application’s requirements.
Simplified Inventory Management
A programmable LED driver can support multiple output-current requirements, helping lighting manufacturers reduce inventory complexity and improve production flexibility.
NFC Programmable LED Driver
ANTRON Programmable LED Drivers use NFC technology to simplify output-current configuration. The driver settings can be programmed using an NFC programming tool or compatible smart device without requiring traditional mechanical adjustment methods.
Programming Process
- Select the required output current
- Place the NFC programming tool or smart device near the NFC programming area
- Program the LED driver
- Install the driver in the LED lighting fixture
Output-current programming can be configured with 50 mA precision, providing flexible control for different LED modules and fixture designs.
Key Features
- 25W to 149W Output Power
- NFC-Programmable Output Current
- 50 mA Programming Precision
- Universal Input Voltage: 120-277 VAC and 347 VAC
- 3-in-1 Dimming: PWM, 0-10V, and Resistance
- Programmable Dim-to-1%, Dim-to-10%, or Dim-to-Off
- PFC, Flicker-Free, and Isolated Design
- 2kV to 6kV Surge Protection
- Open-Circuit, Short-Circuit, Over-Voltage, and Over-Temperature Protection
- UL-Certified Dry and Damp Location Applications
- 5-Year Warranty
Universal Input Voltage for Flexible LED Lighting Designs
ANTRON Programmable LED Drivers are available with input voltage options for 120-277 VAC and 347 VAC, providing flexible solutions for commercial, industrial, and indoor LED lighting applications.
Reliable Protection for LED Lighting Systems
ANTRON Programmable LED Drivers incorporate PFC, flicker-free operation, and isolated design to provide stable and reliable power for LED lighting fixtures.
Built-in protection functions include:
- Open-circuit protection
- Short-circuit protection
- Over-voltage protection
- Over-temperature protection
- 2kV to 6kV surge protection
Selected models also support UL Class 2 and Class P requirements, making them suitable for a wide range of LED lighting applications.
3-in-1 Dimming Control
ANTRON Programmable LED Drivers support multiple dimming methods for flexible lighting control:
- PWM Dimming
- 0-10V Dimming
- Resistance Dimming
Combined with programmable output current and adjustable minimum dimming levels, the driver can be configured for a wide range of LED lighting applications.
Features
– Universal input voltage 120-277, 347Vac
– PFC, Flicker Free, Isolated design
– Programming output current step with 50mA precision
– Dim-to-off, dim-to-1%, dim-to-10% programmable options
– 3-in-1 Dimming (PWM, 0-10V, Resistance)
– Open/Short/Over-Voltage/Over Temp. protection
– 2kV to 6kV surge protection
– Suitable for UL dry and damp location
– 5 years warranty
Product Specification
| Model Name | Voltage VAC(Input) | Power W(Output) | Current mA (Output) | Voltage V (Output) | Efficiency %(Output) | Dimension(mm) | File |
|---|---|---|---|---|---|---|---|
| PAC1250S25DL-AM49 | 120-277 | 25 | 350-1250 | 15-55 | 80 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1250S25DL-AM111 | 120-277 | 25 | 350-1250 | 15-55 | 80 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1250S25DL-AM159 | 120-277 | 25 | 350-1250 | 15-55 | 80 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1250S30DL-AM49 | 120-277 | 30 | 350-1250 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1250S30DL-AM111 | 120-277 | 30 | 350-1250 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1250S30DL-AM159 | 120-277 | 30 | 350-1250 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1400S40DL-AM49 | 120-277 | 40 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1400S40DL-AM111 | 120-277 | 40 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1400S40DL-AM159 | 120-277 | 40 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1400S50DL-AM49 | 120-277 | 50 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1400S50DL-AM111 | 120-277 | 50 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| PAC1400S50DL-AM159 | 120-277 | 50 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | |
| PAC1400S60DL | 120-277 | 60 | 700-1400 | 27-55 | 87 | 314*34*27.5 | Download |
| PAC1400S60DL-AM159 | 120-277 | 60 | 700-1400 | 27-55 | 87 | 314*34*27.5 | Download |
| P3C1250S25DL-AM49 | 347 | 25 | 350-1250 | 15-55 | 80 | 158*44*31 / 133*63*30 / 314*34*27.5 | |
| P3C1250S25DL-AM111 | 347 | 25 | 350-1250 | 15-55 | 80 | 158*44*31 / 133*63*30 / 314*34*27.5 | |
| P3C1250S25DL-AM159 | 347 | 25 | 350-1250 | 15-55 | 80 | 158*44*31 / 133*63*30 / 314*34*27.5 | |
| P3C1250S30DL-AM49 | 347 | 30 | 350-1250 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| P3C1250S30DL-AM111 | 347 | 30 | 350-1250 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| P3C1250S30DL-AM159 | 347 | 30 | 350-1250 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| P3C1400S40DL-AM49 | 347 | 40 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | |
| P3C1400S40DL-AM111 | 347 | 40 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | |
| P3C1400S40DL-AM159 | 347 | 40 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| P3C1400S50DL-AM49 | 347 | 50 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| P3C1400S50DL-AM111 | 347 | 50 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| P3C1400S50DL-AM159 | 347 | 50 | 400-1400 | 15-55 | 85 | 158*44*31 / 133*63*30 / 314*34*27.5 | Download |
| P3C1400S60DL-AM24L | 347 | 60 | 700-1400 | 27-55 | 87 | 314*34*27.5 | Download |
| P3C1400S60DL-AM159 | 347 | 60 | 700-1400 | 27-55 | 87 | 314*34*27.5 | Download |
Product Specification
| Model Name | Voltage VAC(Input) | Power W(Output) | Current mA (Output) | Voltage V (Output) | Efficiency %(Output) | Dimension(mm) | File |
|---|---|---|---|---|---|---|---|
| PAC2100S80DL-AM105 | 120-277 | 80 | 1050-2100 | 27-55 | 87 | 395*38*27.5 / 241*61*37 | Download |
| PAC2100S80DL-AM145 | 120-277 | 80 | 1050-2100 | 27-55 | 87 | 395*38*27.5 / 241*61*37 | Download |
| PAC2750S98DL-AM105 | 120-277 | 98 | 1400-2750 | 27-55 | 87 | 395*38*27.5 / 241*61*37 | Download |
| PAC2750S98DL-AM145 | 120-277 | 98 | 1400-2750 | 27-55 | 87 | 395*38*27.5 / 241*61*37 | Download |
| P3C2100S80DL-AM105 | 347 | 80 | 1050-2100 | 27-55 | 87 | 395*38*27.5 / 241*61*37 | Download |
| P3C2100S80DL-AM145 | 347 | 80 | 1050-2100 | 27-55 | 87 | 395*38*27.5 / 241*61*37 | Download |
| P3C2750S98DL-AM145 | 347 | 98 | 1400-2750 | 27-55 | 87 | 395*38*27.5 / 241*61*37 | Download |
Applications
- LED Panel Lights
- Linear LED Fixtures
- Troffers
- Commercial Lighting
- Indoor LED Lighting
- Industrial Lighting
- OEM and ODM LED Lighting Products
What is a programmable LED driver?
A programmable LED driver is a constant-current LED driver that allows the output current to be configured according to the requirements of the LED lighting fixture.
How is the ANTRON programmable LED driver configured?
The output current can be configured using NFC programming tools or compatible smart devices.
What is the programming precision?
The output current can be programmed with 50 mA precision.
What dimming methods are supported?
The driver supports PWM, 0-10V, and resistance dimming.
What is the difference between a programmable LED driver and a current selectable LED driver?
A programmable LED driver allows the output current to be digitally configured, while a current selectable LED driver typically uses predefined output-current settings selected through a DIP switch or other hardware interface.
Note: The output current can be customized in factory
