Waterproof LED Driver CV 150W-200W AM168
Case: AM168 Size: L: 24.1 cm W: 6.8 cm H: 4.05 cm
Features
– Universal input voltage 120-277, 347Vac
– Constant voltage options 12/24/36/48V
– Waterproof exclosure with IP67 rating for outdoor
– PFC, Flicker Free, Isolated design
– 3-in-1 Dimming (PWM, 0-10V, Resistance)
– Open/Short/Over-Voltage/Over Temp. protection
– Suitable for UL dry and damp location
– 2kV to 6kV surge protection
– 5 years warranty
Waterproof Constant Voltage LED Driver Series Overview 60W-200W
Model Name |
Input Voltage |
Output Power |
Output Current |
Output Voltage |
Efficiency |
AV_YY_S60D |
120-277Vac |
60W |
5A｜2.5 A｜1.67A｜1.25A |
12V｜24V｜36V｜48V |
87% |
AV_YY_S100D |
120-277Vac |
100W |
8A｜4.17 A｜2.78A｜2.08A |
12V｜24V｜36V｜48V |
89% |
AV_YY_S150D |
120-277Vac |
150W |
12.5A｜6.25 A｜4.17A｜3.13A |
12V｜24V｜36V｜48V |
90% |
AV_YY_S200D |
120-277Vac |
200W |
8.34A｜5.56 A｜4.17A |
24V｜36V｜48V |
90% |
3V_YY_S60D |
347Vac |
60W |
5A｜2.5 A｜1.67A｜1.25A |
12V｜24V｜36V｜48V |
87% |
3V_YY_S100D |
347Vac |
100W |
8A｜4.17 A｜2.78A｜2.08A |
12V｜24V｜36V｜48V |
89% |
3V_YY_S150D |
347Vac |
150W |
12.5A｜6.25 A｜4.17A｜3.13A |
12V｜24V｜36V｜48V |
90% |
3V_YY_S200D |
347Vac |
200W |
8.34A｜5.56 A｜4.17A |
24V｜36V｜48V |
90% |
Note: The model name YY is output voltage which can be 12/24/36/48V depends on model
Wire Diagram
