T8 Instant Start Ballasts 17W-40W_AM103_3-4 Lamps
Case: AM103 Size: L: 24.1 cm W: 4.3 cm H: 3.05 cm
Features
● Three or Four Lamps
● Sound Rated Class A
● Auto Restart
● UL/cUL Listed
● Class P Thermally Protected
● No PCBs
● UL Type 1 Outdoor
● High Power Factor
● Type HL
● FCC part 18 Class A
● Surge Protected
● DOE Energy Verified
● NRCan Energy Verified
T8 Instant Start Ballasts 17W-40W_AM103_3-4 Lamps Series Overview
Model Name |
Starting Method |
Input voltage |
Lamp type |
Rated Lamp Watts |
No. of Lamp |
EPQ-332T8M |
Instant Start |
347V |
F32T8 |
32W |
4 |
3 |
|||||
F25T8 |
25W |
4 |
|||
3 |
|||||
F17T8 |
17W |
4 |
|||
3 |
|||||
F40T8 |
40W |
3 |
|||
F32T8/ES(30W) |
30W |
4 |
|||
3 |
|||||
F32T8/ES(28W) |
28W |
4 |
|||
3 |
|||||
F32T8/ES(25W) |
25W |
4 |
|||
3 |
|||||
EPQ-332T8MLO |
Instant Start |
347V |
F32T8 |
32W |
4 |
3 |
|||||
F25T8 |
25W |
4 |
|||
3 |
|||||
F17T8 |
17W |
4 |
|||
3 |
|||||
F40T8 |
40W |
3 |
|||
F32T8/ES(30W) |
30W |
4 |
|||
3 |
|||||
F32T8/ES(28W) |
28W |
4 |
|||
3 |
|||||
F32T8/ES(25W) |
25W |
4 |
|||
3 |
|||||
EPQ-A32T8M |
Instant Start |
120-277V |
F32T8 |
32W |
4 |
3 |
|||||
F25T8 |
25W |
4 |
|||
3 |
|||||
F17T8 |
17W |
4 |
|||
3 |
|||||
F40T8 |
40W |
3 |
|||
F32T8/ES(30W) |
30W |
4 |
|||
3 |
|||||
F32T8/ES(28W) |
28W |
4 |
|||
3 |
|||||
F32T8/ES(25W) |
25W |
4 |
|||
3 |
|||||
EPQ-A32T8MLO |
Instant Start |
120-277V |
F32T8 |
32W |
4 |
3 |
|||||
F25T8 |
25W |
4 |
|||
3 |
|||||
F17T8 |
17W |
4 |
|||
3 |
|||||
F40T8 |
40W |
3 |
|||
F32T8/ES(30W) |
30W |
4 |
|||
3 |
|||||
F32T8/ES(28W) |
28W |
4 |
|||
3 |
|||||
F32T8/ES(25W) |
25W |
4 |
|||
3 |
Wire Diagram
Four Lamps
Three Lamps
