Microwave Occupancy LED Driver CV 60W AM103

Case: AM103  Size: L: 24.1 cm W: 4.3 cm H: 3.05 cm



– Universal input voltage 120-277Vac
– Sensor is an option component for all Antron driver
– Sensitivity and time delay adjustable
– 2kV to 4kV surge protection
– 3-in-1 Dimming (PWM, 0-10V, Resistance)
– Open/Short/Over-Voltage/Over Temp. protection
– Suitable for UL dry and damp location
– 5 years warranty

Microwave Occupancy Constant Voltage Series Overview (60W-100W)

Model Name Input Voltage Output Power Output Current Output Voltage Efficiency
AV12S60D-EOS 120-277Vac 60W 5000mA 12V 89%
AV24S60D-EOS 120-277Vac 60W 2500mA 24V 89%
AV24S100D-EOS 120-277Vac 100W 4100mA 24V 89%

Note: The output current can be customized in factory

Model Name Time Delay Sensitivity Cover Area
Microwave Sensor 1 second to 15 minutes 0~10 meters 45°~135°


Cover Area -Ceiling:                                    Cover Area -Wall:

Wire Diagram



Output Model Constant Voltage
Input Voltage 120-277V
Input Frequency 50/60 Hz
Dimming 3 in 1 ( PWM, 1-10V, Resistance)
Dimming 1-100%
Surge Rating 2KV
Warranty 5 Years TC≦75˚C
3 Years 75˚C≦TC≦90˚C


* Only “Made in Taiwan” products can meet TAA compliant.

AV12S60D-EOS AM103


AV24S60D-EOS AM103
