Constant Current LED Driver 40W AM188 (None-Dimming)

Case: AM188  Size: L: 15.4 cm W: 3.2 cm H: 2.9 cm



– Universal input voltage 120-277Vac
– Mini form factor
– Low cost and high reliability
– PFC, Flicker Free, Isolated design
– Open/Short/Over-Voltage/Over Temp. protection
– 2kV surge protection
– Suitable for UL dry and damp location
– 5 years warranty

Constant Current Series Overview (5W-40W Non-Dimming)

Model Name Input Voltage Output Power Output Current Output Voltage Efficiency
AC350S5M 120-277Vac 5W 350mA 9-14V 83%
AC500S5M 120-277Vac 5W 500mA 6-10V 83%
AC700S5M 120-277Vac 5W 700mA 5-7V 83%
AC1050S5M 120-277Vac 5W 1050mA 3-5V 83%
AC350S12M 120-277Vac 12W 350mA 20-34V 85%
AC500S12M 120-277Vac 12W 500mA 15-24V 85%
AC700S12M 120-277Vac 12W 700mA 11-17V 85%
AC1050S12M 120-277Vac 12W 1050mA 7-11V 85%
AC1050S40 120-277Vac 40W 1050mA 22-38V 88%

Note: The output current can be customized in factory

Wire Diagram



Output Model Constant Current
Input Voltage 120-277V
Input Frequency 50/60 Hz
Dimming NA
Surge Rating 2KV
Warranty 5 Years TC≦75˚C
3 Years 75˚C≦TC≦90˚C


* Only “Made in Taiwan” products can meet TAA compliant.

AC1050S40 AM188
