30W UHV Self-Diagnostic Emergency LED Driver AM247
Case: AM247 Size: L: 32cm W: 5.7cm H: 5.2 cm
Features
– Universal input voltage 120-277Vac
– At least 90 minutes in emergency mode
– automatically operate a 30 seconds short‐term test each month
– automatically operate a 90 minutes duration test every 12 months
– Open/Short/Over-Voltage/Over Temp. protection
– Suitable for UL dry and damp location
– UL listed and CEC title 20 approval
– 5 years warranty
30W Self-Diagnostic Emergency LED Driver AM247 Overview
Model Name
|
Input Voltage
|
Output Power
|
Output Current
|
Output Voltage
|
Flexible Conduit
|
Dimension
|
SDEMAP30-255
|
120-277Vac
|
30W
|
660-180mA
|
50-255V
|
None
|
320*57*52mm
|
*UL Pending
Wire Diagram
