25W-30W UHV Power Activate Self-Diagnostic Emergency LED Driver AM247

Case: AM247  Size: L: 32cm W: 5.7cm H: 5.2 cm




– Universal input voltage 120-277Vac
– At least 90 minutes in emergency mode
– automatically operate a 30 seconds short‐term test each month
– automatically operate a 90 minutes duration test every 12 months
– Open/Short/Over-Voltage/Over Temp. protection
– Suitable for UL dry and damp location
– UL listed and CEC title 20 approval
– 5 years warranty

25W-30W Self-Diagnostic Emergency LED Driver  AM247 Overview

Model Name Input Voltage Output Power Output Current Output Voltage Flexible Conduit Dimension
SDLEDS30-50255-25.6CHPNBO 25W* 120-277Vac 25W 500-98mA 50-255V None 320*57*52mm
SDLEDS30-50255-25.6CHPNBO* 120-277Vac 30W 600-118mA 50-255V None 320*57*52mm
4SDLEDS30-50255-25.6CHPNBO* 347-480Vac 30W 660-180mA 50-255V None 320*57*52mm
*UL Pending

Wire Diagram


Output Model Constant Power
Input Voltage 120-277V,347-480V
Input Frequency 50/60 Hz
Dimming NA
Surge Rating 3KV
Warranty 5 Years TC≦60˚C
3 Years TC≦70˚C


* Only “Made in Taiwan” products can meet TAA compliant.

SDLEDS30-50255-25.6CHPNBO 25W AM247


SDLEDS30-50255-25.6CHPNBO AM247


4SDLEDS30-50255-25.6CHPNBO AM247
