14W NV CP Emergency LED Driver Conduit AM209

Case: AM209  Size: L: 30.4 cm W: 4.3 cm H: 3.05 cm
With Flexible Conduit and Plastic Plate



– Universal input voltage 120-277, 120-347Vac
– At least 90 minutes in emergency mode
– Emergency pack is compatible with any AC driver
– High quality LiFePO4 battery inside
– Open/Short/Over-Voltage/Over Temp. protection
– Suitable for UL dry and damp location
– UL listed and CEC title 20 approval
– 5 years warranty

14W Constant Power Emergency LED Driver Conduit  AM209 Overview

Model Name Input Voltage Output Power Output Current Output Voltage Flexible Conduit Dimension
EMLEDS14-1555-9.6CHPNB-FT 120-277Vac 14W 935-250mA 15-55V Double 304*43*30.5mm
MEMLEDS14-1555-9.6CHPNB-FT 120-347Vac 14W 935-250mA 15-55V Double 304*43*30.5mm

Wire Diagram


Output Model Constant Power
Input Voltage 120-277V, 120-347V
Input Frequency 50/60 Hz
Dimming NA
Surge Rating 3KV
Warranty 5 Years TC≦60˚C
3 Years TC≦66˚C


* Only “Made in Taiwan” products can meet TAA compliant.

EMLEDS14-1555-9.6CHPNB-FT AM209


MEMLEDS14-1555-9.6CHPNB-FT AM209
